Flight Report Fw 190, Serial Nr. 1286 Nr. 4

S.O.Archiv Werk Flughafen

Date: Fl. Nr.: Take-off: Landing: Duration: Pilot: 30.6. 39 10.34 10.44 0.10 Bartsch 30.6. 40 15.50 16.05 0.15 Melhorn   1.7. 41 17.11 17.25 0.14 Tank   1.7. 42 19.00 19.05 0.05 Sander   7.7. 43 16.04 16.11 0.07 Tank   7.7. 44 16.28 16.50 0.22 Tank   7.7. 45 17.30 17.40 0.10 Melhorn   7.7. 46 19.34 19.50 0.16 Melhorn   7.7. 47 21.10 21.25 0.15 Sander   8.7. 48 18.46 18.55 0.09 Sander   9.7. 49 11.55 12.12 0.17 Märschel   9.7. 50 15.50 16.20 0.30 Kampmeier 18.8. 51 12.15 12.53 0.38 Märschel 19.8. 52   9.00   9.51 0.51 Kampmeier 20.8. 53 16.30 17.11 0.41 Märschel Condition: Engine BMW 801 D 2/305475. Close engine cowling. Split cowl flaps. Fixed inner wheel fairings ETC 501 with intermediate rack moved forward 250 mm Armament: 2 MG 151 without ammunition Loading for rearmost CG : 500 kg bomb, 160 lb. ballast in the FT area (2.95 m behind center front spar). a)   2 x 50 kg wood bombs with mounting brackets as per SK 8752 b)   1000 kg wood bomb Program: 1. Level speeds with a 1000 kg mine bomb (wood). 2. Level speeds with 2 x 50 kg bombs (wood) per wing. 3. Flight characteristics with the 50-kg bombs and brackets as per SK. 8752. Results: 1. The flights to determine the level speeds were conducted with a wooden bomb, in order not to have to drop the bombs on each landing. As the attached graph shows, the speed loss caused by a 1,000 kg bomb is 20-21 mph (32-34 km/h) at combat power. 2.+3. The 4 x 50 kg bombs with the wing racks also results in a level speed loss of 20-21 mph (32-34 km/h) at n = 2400 rpm. Regarding flight characteristics these bomb racks are alright. Separation phenomena, causing a disturbance of flow at the aileron, did not occur. Remarks: The flight testing of this machine is completed. Langenhagen, 24 August 1943 Gt/Sp
